19OPERATING THE TRACTOR
C Suspension adjustment
[B3030 and B3000 only]
Turn the suspension adjust knob to achieve the optimum
suspension setting.
C Armrest angle adjustment
The armrest angle can be adjusted by the hex socket bolt
(socket size 7/32").
BSeat Belt
To avoid personal injury:
A Always use the seat belt when the ROPS and
CAB is installed.
A Do not use the seat belt if a foldable ROPS is
down or there is no ROPS.
Adjust the seat belt for proper fit and connect to the
buckle. The seat belt is auto-locking retractable type.
BTilt Steering Adjustment
To avoid personal injury:
A Do not adjust the steering wheel while the
tractor is in motion.
Press down the steering wheel pedal, to release the lock
so the steering wheel can be adjusted to one of three
desired positions.
(1) Suspension adjust knob (A) To decrease tension
(B) To increase tension
(1) Hex socket bolt
(1) Seat belt
(1) Steering wheel tilt pedal (A) "PRESS DOWN"
