Kubota BX2350 User Manual

CAB OPERATION44
ENGLISH
BRear Window
BFront Window
To open.................... Turn both the rear window
handles counterclockwise to the
vertical position (turn 90 ). Push
the rear window a little and it will
be opened by the gas spring
cylinder.
To close.................... Pull the rear window a little and
turn both the rear window
handles clockwise (90 ). Insert
both the handles inside the lock
holes.
(1) Rear window handle
(2) Lock hole
(A) "OPEN"
(B) "CLOSE"
To open.................... Turn both the front window
handles counterclockwise to the
vertical position (turn 90 ). Push
the front window a little and it will
be opened by the gas spring
cylinder.
To close.................... Pull the front window a little and
turn both the front window
handles clockwise (90 ). Insert
both the handles inside the lock
holes.
(1) Front window handle
(2) Lock hole
(A) "OPEN"
(B) "CLOSE"
Lock when opening... To lock the front window when it
is opened, insert the lever to the
front window handle.
(1) Front window handle
(2) Lock lever
(A) "LOCK"
(B) "UNLOCK"

Kubota BX2350 Specifications

General

Engine Type	Diesel
Engine Power	23 hp
Transmission	Hydrostatic
Fuel Capacity	6.6 gallons
PTO Power	17.7 hp
Wheelbase	55.1 inches
Drive	4WD
Engine Model	Kubota D902
Rated RPM	3200 rpm
Hydraulic System Type	Open center
3-Point Hitch	Category I
PTO Speed	540 rpm
Width	44.5 inches
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Displacement	54.8 cu in (898 cc)
