S-7
SM-E2B SERIES, WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W10138740
Item Factory Specification Allowable Limit
Crankpin to Crankpin Bearing
Crankpin
Crankpin Bearing
Oil Clearance
O.D.
I.D.
0.020 to 0.051 mm
0.00079 to 0.00201 in.
33.959 to 33.975 mm
1.33697 to 1.33760 in.
33.995 to 34.010 mm
1.33839 to 1.33898 in.
0.15 mm
0.0059 in.
–
–
Crankshaft Journal to Crankshaft Bearing
1 [Z482/D662/D722/D782-E2B]
Crankshaft Journal
Crankshaft Bearing 1
Oil Clearance
O.D.
I.D.
0.034 to 0.106 mm
0.00134 to 0.00417 in.
39.934 to 39.950 mm
1.57221 to 1.57284 in.
39.984 to 40.040 mm
1.57417 to 1.57638 in.
0.20 mm
0.0079 in.
–
–
Crankshaft Journal to Crankshaft Bearing
1 [Z602/D902-E2B]
Crankshaft Journal
Crankshaft Bearing 1
Oil Clearance
O.D.
I.D.
0.034 to 0.106 mm
0.00134 to 0.00417 in.
43.934 to 43.950 mm
1.72968 to 1.73031 in.
43.984 to 44.040 mm
1.73165 to 1.73386 in.
0.20 mm
0.0079 in.
–
–
Crankshaft Journal to Crankshaft Bearing
2 (Flywheel Side)
Crankshaft Journal
Crankshaft Bearing 2
Oil Clearance
O.D.
I.D.
0.028 to 0.059 mm
0.00110 to 0.00232 in.
43.934 to 43.950 mm
1.72968 to 1.73031 in.
43.978 to 43.993 mm
1.73142 to 1.73201 in.
0.20 mm
0.0079 in.
–
–
Crankshaft Journal to Crankshaft Bearing
3 (Intermediate)
[Z482/D662/D722/D782-E2B]
Crankshaft Journal
Crankshaft Bearing 3
Oil Clearance
O.D.
I.D.
0.028 to 0.059 mm
0.00110 to 0.00232 in.
39.934 to 39.950 mm
1.57221 to 1.57284 in.
39.978 to 39.993 mm
1.57394 to 1.57453 in.
0.20 mm
0.0079 in.
–
–
Crankshaft Journal to Crankshaft Bearing
3 (Intermediate) [Z602/D902-E2B]
Crankshaft Journal
Crankshaft Bearing 3
Oil Clearance
O.D.
I.D.
0.028 to 0.059 mm
0.00110 to 0.00232 in.
43.934 to 43.950 mm
1.72968 to 1.73031 in.
43.978 to 43.993 mm
1.73142 to 1.73201 in.
0.20 mm
0.0079 in.
–
–
KiSC issued 06, 2006 A
