Kubota KX015-4 User Manual

Assembly and functions
56
Coolant radiator and oil cooler
The coolant radiator and the oil cooler are located under the side cover.
1. Coolant radiator
2. Oil cooler
3. Tank breather filter
Do not unscrew the tank breather filter plug (4). The
tank breather filter is not serviceable.
1
2
3
4

Kubota KX015-4 Specifications

General

Make	Kubota
Model	KX015-4
Category	Excavators
Max Dig Depth	2250 mm
Engine	Kubota D782
Transport Width	990 mm
Bucket Capacity	0.04 m3 / 1.41 ft3
