M6800 · M6800S · M8200 · M9000, WSM
FRONT AXLE
2. SERVICING SPECIFICATIONS
[2WD TYPE]
W1013874
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 1.0 to 5.0 mm
0.04 to 0.20 in.
–
Front Wheel Steering Angle
Axial Sway
Radial Sway
0.925 to 0.960 rad
53 to 55 °
5.0 mm
0.197 in.
5.0 mm
0.197 in.
–
–
–
Front Axle Swing Angle 0.157 to 0.227 rad
9 to 13 °
–
Front Axle Middle Boss to Bracket Bushing
Front Axle Middle Boss
Bracket Bushing
Clearance
O.D.
I.D.
0.050 to 0.150 mm
0.00197 to 0.00590 in.
39.938 to 40.000 mm
1.57236 to 1.57480 in.
40.050 to 40.088 mm
1.57677 to 1.57827 in.
0.35 mm
0.0138 in.
–
–
Knuckle Shaft to Bushing
Knuckle Shaft
Bushing
Clearance
O.D.
I.D.
0.020 to 0.125 mm
0.00079 to 0.00492 in.
37.975 to 38.000 mm
1.49508 to 1.49606 in.
38.020 to 38.100 mm
1.49685 to 1.50000 in.
0.35 mm
0.0138 in.
–
–
Knuckle Shaft Thrust Collar Thickness 3.0 mm
0.12 in.
–
Front Wheel Hub Turning Torque 2.94 to 4.90 N·m
0.3 to 0.5 kgf·m
2.17 to 3.62 ft-lbs
–
