10-S6
M6800 · M6800S · M8200 · M9000, WSM
CABIN
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Air-gap of A/C Compressor Magnet Clutch Swash Plate Type
Compressor
Scroll Type
Compressor
0.25 to 0.50 mm
0.010 to 0.020 in.
0.35 to 0.65 mm
0.014 to 0.022 in.
–
–
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Condition
• Engine Speed : Approx. 1500 min
−1
(rpm)
• Ambient Temperature : 30 to 35 °C
86 to 95 °F
• Blower Switch : PURGE Position
Pressure (LO
Pressure Side)
Pressure
(HI Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure
Side)
Setting Pressure
(HI Pressure Side)
Less than
approx. 0.196 MPa
2.0 kgf/cm
2
28.4 psi
More than
approx. 3.14 MPa
32 kgf/cm
2
455 psi
–
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.39 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbs) of force
–
Proper Clutch Pedal Free Travel 35 to 45 mm
1.38 to 1.77 in.
–
Proper Brake Pedal Free Travel 40 to 45 mm
1.57 to 1.77 in.
–
Shift Rod (M6800SQ) Length Approx. 275 mm
10.8 in.
–
Shift Rod (M8200Q, M9000Q) Length Approx. 155 mm
6.10 in.
Hydraulic Control Rod
Position and Draft Rod (M6800SQ)
Length Approx. 362 mm
14.25 in.
–
Hydraulic Control Rod
Position and Draft Rod
(M8200Q, M9000Q)
Length Approx. 264 mm
10.39 in.
–
