91PERIODIC SERVICE
EVERY 300 HOURS
BChanging Engine Oil
To avoid personal injury:
A Be sure to stop the engine before changing the
oil.
A Allow engine to cool down sufficiently, oil can
be hot and can burn.
1. To drain the used oil, remove the drain plug at the
bottom of the engine and drain the oil completely into
the oil pan.
All the used oil can be drained out easily when the
engine is still warm.
2. After draining reinstall the drain plug.
3. Fill with the new oil up to the upper notch on the
dipstick.
(See "LUBRICANTS" in "MAINTENANCE" section.)
BReplacing Hydraulic Oil Filter
C Cleaning Magnetic Filter
To avoid personal injury:
A Be sure to stop the engine before changing the
oil filter cartridge.
A Allow engine to cool down sufficiently, oil can
be hot and can burn.
1. Remove the drain plug at the bottom of the
transmission case and drain the oil completely into an
oil pan.
2. After draining reinstall the drain plug.
(1) Adjusting bolt
(2) Tension pulley mounting nut
(A) Check the belt tension
Oil capacity
with filter
M7040 11 L
M8540 10.7 L
(1) Oil inlet
(2) Dipstick
(A) Oil level is acceptable within this range
(1) Drain plug
To Next Page
