U20-3, U25-3 WSM Machine body (Mechanism section)
II-M-13
• Retractable undercarriage (U20-3 only)
U20-3
× : required — : not required
No. PART No. PART NAME Q’ty Rubber crawler Steel crawler
140 06331-35012 Plug 8 × —
150 RB411-21812 Plate 4 — ×
160 01133-61220 Bolt 8 — ×
170 04013-60120 Washer, plain 8 — ×
180 RB411-21820 Guide, crawler 4 — ×
190 01133-61020 Bolt 12 — ×
200 RB411-22310 Crawler, rubber 2 × —
210 RB411-22100 Assy, crawler 2 — ×

Kubota U20-3 Specifications

General

Tail Swing Type	Conventional
Engine Gross Power	24.5 kW
Max Reach at Ground Level	4, 490 mm
Max Dumping Height	2, 480 mm
Travel Speed	2.5 km/h
