Assembly and functions
Other equipment at the operator's place
Other equipment located at and around the operator's place is described below.
Interior lighting
An interior light (1) is located on the left side of the cab roof. It is
turned on and off with the switch (2).
Fuse box
The fuse box (1) is located below the operator's seat behind a cov-
er.
Tool compartment
The tool compartment (1) is located below the operator's seat be-
hind a cover plate.
1
1

Kubota U27-4 Specifications

General

Make	Kubota
Model	U27-4
Category	Compact Excavator
Bucket Capacity	0.08 m3
Max Dig Depth	2.82 m
