Kubota U27-4 User Manual

Assembly and functions
RH418-8135-3 53
07/2015
Hydraulic oil tank
The hydraulic oil tank contains the suction filter and the return filter.
1. Breather filter
2. Oil fill opening for hydraulic oil
3. Hydraulic oil tank
4. Sight glass for hydraulic oil level
Coolant radiator and hydraulic oil radiator
To the rear of the right ventilation grille at the rear of the excavator, are the coolant radiator and hydraulic oil radi-
ator.
The fill opening for the coolant radiator is located beneath the right side cover.
1. Coolant radiator
2. Hydraulic oil radiator
1 2 3
4
1
2

Kubota U27-4 Specifications

General

Make	Kubota
Model	U27-4
Category	Compact Excavator
Bucket Capacity	0.08 m3
Max Dig Depth	2.82 m
