3-S4
B1710 · B2110 · B2410 · B2710, WSM
TRANSMISSION
2. SERVICING SPECIFICATIONS
W10138740
Item Factory Specification Allowable Limit
Check and High Pressure Relief Valve Setting Pressure
[Relief Valve]
31.5 to 32.5 MPa
321 to 331 kgf/cm
2
4568 to 4712 psi
–
Charge Relief Valve Setting Pressure 350 to 450 kPa
3.6 to 4.6 kgf/cm
2
50.8 to 65.3 psi
–
Shift Fork to Shift Gear Groove Clearance 0.10 to 0.35 mm
0.004 to 0.014 in.
0.5 mm
0.020 in.
13T Gear to 3rd Shaft
3rd Shaft
13T Gear
Needle
Clearance
O.D.
I.D.
O.D.
0.007 to 0.046 mm
0.00028 to 0.00181 in.
21.987 to 22.000 mm
0.86562 to 0.86614 in.
30.007 to 30.021 mm
1.18138 to 1.18193 in.
3.994 to 4.000 mm
0.15724 to 0.15748 in.
0.1 mm
0.004 in.
–
–
–
16T-20T Gear to Front Wheel Drive Shaft
Front Wheel Drive Shaft
16T-20T Gear
Needle
Clearance
O.D.
I.D.
O.D.
0.027 to 0.067 mm
0.00106 to 0.00264 in.
21.967 to 21.980 mm
0.86484 to 0.86535 in.
28.007 to 28.021 mm
1.10264 to 1.10319 in.
2.996 to 3.000 mm
0.11795 to 0.11811 in.
0.1 mm
0.004 in.
–
–
–
11T Gear, One-way Clutch Cam to Mid-
PTO Shaft
Mid-PTO Shaft
11T Gear and One-way Clutch Cam
Needle
Clearance
O.D.
I.D.
O.D.
0.020 to 0.026 mm
0.00078 to 0.00102 in.
19.989 to 20.000 mm
0.78697 to 0.78740 in.
24.007 to 24.020 mm
0.94516 to 0.94567 in.
1.997 to 2.000 mm
0.07862 to 0.07874 in.
0.1 mm
0.004 in.
–
–
–
Spiral Bevel Pinion Side Clearance Less than 0.15 mm
Less than 0.0059 in.
–
Spiral Bevel Pinion to Spiral Bevel Gear
Adjusting Shim
Backlash
Thickness
0.10 to 0.20 mm
0.0039 to 0.0079 in.
0.2 mm, 0.008 in.
0.5 mm, 0.020 in.
–
–
KiSC issued 11, 2006 A
