G-35
ZD25F, WSM
G GENERAL
[11] CHECK POINT OF EVERY 2 YEARS
Replacing Hydraulic Hose
1. Replace the hose.
Refer to “Checking Hydraulic Hose”. (See page G-30.)
W1067327
Replacing Radiator Hose
1. Replace the hoses and clamps.
Refer to “Checking Radiator Hose and Hose Clamp”. (See page
G-30.)
W1067436
Replacing Fuel Lines
1. Replace the fuel line.
Refer to “Checking Fuel Lines and Fuel Filter”. (See page G-27.)
W1082371
Replacing Intake Air Line
1. Replace the intake air line.
Refer to “Checking Intake Air Line”. (See page G-31.)
W1052932
Replacing Mower Gear Box Seals
1. Replace the mower gear box oil seals (1), (2).
Refer to “Disassembling Gear Box Assembly”. (See page 6-S8.)
W1038357
(1) Oil Seal (2) Oil Seal
KiSC issued 04, 2009 A

Kubota ZD28F Specifications

General

Engine Type	Diesel
Horsepower	28 hp
Transmission	Hydrostatic
Weight	1, 433 lbs
Type	Zero-Turn Mower
Displacement	68.5 cu in
Turning Radius	Zero
