Disc mower
38
GMD240-280-310
Putting into service
KN204AGB H
Hydraulic connections
- Connect hydraulic hose (1) of the transport/work
cylinder to a single acting valve with float position.
Electrical connection
When the following equipment is fitted:
Mechanical safety release + Hydraulic pivot +
Lighting and signalling
- Connect the hydraulic hoses for the
mechanical safety release with hydraulic
pivot to the additional double acting valve.
When optional equipment is used, follow
specific procedures mentioned in the related
section:
• Optional equipment / Lighting and
signalling.
