Putting into service
Disc mower
GMD240-280-310
37
KN204AGB H
Coupling the machine
- Lower the tractor three-point linkage.
- Position ball joints of tractor lower links in line with
machine lower yokes.
- Attach the lower links to the hitch pins.
- Attach top link (1) in one of the upper holes on the
tractor side.
- Place release cord handle in the tractor cab.
- Lift machine using tractor hydraulic lift linkage.
- Fold and lock parking latch (1) using spring (2).
- Fold parking stand (1) upwards and lock it in place.
It is recommended to couple the left lower link
first.
When optional equipment is used, follow
specific procedures mentioned in the related
section:
• Optional equipment / Chain stroke
limiter.
The parking latch must always be locked for
work and transport.
