Disc mower
66
GMD240-280-310
Maintenance and storage
KN204AGB H
Grease
• The release sheath.
When the following equipment is fitted:
Mechanical safety release
- Loosen nut (1) to release lock (2).
- a: Remove tie-rod (1).
- Grease the release sheath inside.
- b: Reinstall tie-rod (1).
- Tighten nut (1).
- Make sure lock is engaged (2).
- Measure dimension L:
• L= 95 mm (3.7’’).
(See section: Instructions for work / Machine
use / Machine safety / Basic adjustment).
