Maintenance and storage
Disc mower
GMD240-280-310
73
KN204AGB H
Check angle gearbox oil level
- Regularly check the oil level:
- Place the cutterbar in horizontal position.
- Remove drain plug (1) and its washer.
- Check the oil level: The oil level must reach the lower
edge of the emptying hole (1).
- Top up if necessary.
- Clean and reinstall drain plug (1) and its washer.
Replace if necessary.
Breather plug checking and cleaning
From the working position:
- Remove breather plug (1) and its seal.
- Clean and check breather plug for good
functioning (1).
- Reinstall breather plug (1) and its seal.
