6. - Putting into service
FC3160TCD-3560TCD-4060TCD
41
KN284DGB B
Mower conditioner
The friction slip clutch is ready to function.
- Loosen nuts to release friction discs (a).
- Let the friction discs slip for a few seconds (b).
- FC3160/3560:Tighten nuts until distance (L) is
34 mm (1.34’’).
- FC4060:Tighten nuts until distance (L) is
33 mm (1.3’’).
Do not fully tighten springs to prevent
damage on drive elements. The springs must
never be coil bound.
Loosen at least by 1/2 turn.
