10. - Optional equipment
KN284DGB B
Mower conditioner
- Check that measure (A) corresponds to 1380 mm
(4’6.33’’).
Readjust if necessary:
- Loosen counter nut (1).
- Rotate cylinder rod using wrench (2) to adjust
the length.
- Tighten counter nut (1).
2
1
Measure (A) is a theoretical measure and may
need finer adjustment depending on the tractor
wheel track in order to allow it to go over the
offset swath.
