Maintenance and storage
Mower conditioner
FC883RA
79
Hydraulic tank
- Place the machine in working position.
- Remove filter screws (1), upper plate(2) and spring
(3).
- Place a container of sufficient capacity under drain
plug (7).
- Remove drain plug (7) and its washer (6).
- Allow oil to drain completely.
- Wait for dripping to stop.
- Clean and reinstall drain plug (7) and its washer (6).
- Replace gasket (6) if necessary.Part no. 82131824.
- Pour the correct oil quantity and quality through the
opening of the filler plug (5).
- Replace the tank filter cartridge.Part no. 57865800.
- Reinstall filler plug (5).
Before draining oil, operate the machine for a
few minutes so that the oil warms up.
The hydraulic tank is filled with 60 L (15.85 US gal) oil type SHELL TELLUS 46 or a mineral hydraulic
oil with a viscosity complying with the standard ISO 46 category HM.
