Mower conditioner
84
FC883RA
Maintenance and storage
- Rotate pin (1) counterclockwise to tension the
conveyor.
- Measure dimension (L):
- If measure (L) is comprised between 1505 mm
(4’11.25’’) and 1510 mm (4’11.44’’).
• The conveyor is tensioned.
- If measure (L) is below 1505:
• Rotate pin (1) counterclockwise to tension the
conveyor.
• Measure dimension (L).
- Reinstall bolt (1) and nut (2).
