OPERATOR'S MANUAL
Disc mower
GMD602 GII
KN011FGB F
- English - 01-2007

Table of Contents

Questions and Answers

  • C
    Christopher MitchellAug 5, 2025
    What to do if it is not possible to place KUHN GMD602 GII in "headland turn" position?
    • D
      Dawn FaulknerAug 5, 2025
      If you cannot place your KUHN Farm Equipment in the "headland turn" position, it might be because the hydraulic circuit was not pressurized correctly. To resolve this, connect the 2 hydraulic hoses of the transport/work position cylinder to a double acting valve with float position. Open the hydraulic valve using the 18mm box spanner supplied with the machine. Shift the tractor hydraulic valve in the direction for placing the machine in working position, to pressurize the circuit to 93 bar (1348 psi). Shut off the hydraulic valve. Shift the tractor's hydraulic valve in float position. The pressure on the gauge drops. Repeat these operations several times until the pressure stays at 93 bar (1348 psi).
  • T
    Tara BowersAug 10, 2025
    Why is my KUHN GMD602 GII Farm Equipment leaving uneven stubble?
    • A
      Andrew GreeneAug 10, 2025
      Uneven stubble when using KUHN Farm Equipment can be caused by several factors: * **Dull or broken knives:** Replace the knives. * **Incorrectly installed knives:** Ensure the arrow on the knife's upper face points in the disc's direction of rotation. * **Too low PTO speed:** Increase the speed to 540 min-1.
  • M
    Marissa MillerAug 15, 2025
    What to do if soil builds up in front of the cutterbar of KUHN GMD602 GII?
    • J
      John MercadoAug 15, 2025
      Soil build-up in front of the cutterbar on your KUHN Farm Equipment can occur due to: * Too much cutterbar down pressure. To fix this, increase the accumulator pressure. * Very wet working conditions. In this case, adjust the main frame height with regards to the ground.
  • A
    Amanda FranklinAug 20, 2025
    Why does my KUHN GMD602 GII have bad ground contour adaptation?
    • H
      Heidi SinghAug 20, 2025
      Bad ground contour adaptation with KUHN Farm Equipment can be attributed to: * Incorrect main frame setting: Adjust the main frame height with regards to the ground. * Excessive ground speed: Reduce ground speed. * Insufficient ground pressure: Reduce accumulator pressure.
  • S
    Scott TaylorAug 26, 2025
    How to improve cutterbar ground clearance of KUHN GMD602 GII Farm Equipment in "headland turn" position?
    • S
      shawn78Aug 26, 2025
      Insufficient cutterbar ground clearance in the "headland turn" position when using KUHN Farm Equipment can result from: * Incorrect tractor lift linkage setting: Refer to the machine attachment instructions. * Too long leveling rod adjustment: Shorten the leveling rods.
  • S
    Sydney SampsonAug 29, 2025
    What causes excessive oscillation of KUHN GMD602 GII Farm Equipment in transport position and how to fix it?
    • H
      haynesashleyAug 29, 2025
      Excessive mowing-conditioning unit lateral oscillation in transport position on KUHN Farm Equipment is caused by an incorrect transport stop adjustment. Readjust the transport stop to resolve this issue.

Summary

Identification of the Machine

Front View

Shows the front view of the disc mower, identifying its main components.

Rear View

Displays the rear view of the disc mower, highlighting its linkage and drive components.

Model Identification Plate

Details the machine's type, serial number, and manufacturer information.

Safety

Description of Symbols

Explains hazard, warning, and information symbols used in the manual and on the machine.

Safety Instructions

General safety rules for operation, maintenance, and repair to prevent accidents.

Safety Decal Locations

Illustrates the placement and meaning of all safety warning decals on the machine.

Road Safety Equipment and Recommendations

Details required safety equipment and regulations for road transport.

Machine Specifications

Description and Glossary

Lists key machine components and defines technical terms used in the manual.

Technical Specifications

Provides essential data like working width, transport dimensions, weight, and power requirements.

Sound Levels

Reports the measured noise emission levels for the tractor and machine combination.

Putting Into Service

Control Elements and Coupling

Identifies machine controls, coupling elements, and basic connection procedures.

Tractor Preparation

Outlines necessary tractor checks and specifications for safe attachment.

PTO Shaft Installation

Provides instructions for correctly connecting the primary PTO shaft to prevent damage.

Machine Adjustments and Hitching

Covers basic adjustments, hitch parallelism, and frame height settings.

Instructions for Transport

Putting Machine into Transport Position

Step-by-step guide to safely convert the mower for transport.

Conformity with Road Regulations

Ensures the machine meets highway code regulations before road use.

Instructions for Work

Putting Machine into Work Position

Steps to safely deploy the mower for field operation.

Adjustments in Working Position

Details on adjusting cutting height and tilt angle for optimal performance.

Ground Pressure Adjustment

Explains how to set hydraulic pressure for ground contour adaptation.

Optional Equipment

Raised Skid Shoes

Information on raised skid shoes for higher cutting and use on sticky grounds.

Side Deflector Kit

Details on side deflectors for mowing dense or down crops.

Large Cone Discs

Information on large cone discs for handling long-stemmed dense or down crops.

Maintenance and Storage

Maintenance Frequency and Lubrication

Schedule for maintenance tasks and detailed lubrication points.

Cutterbar and Gearbox Maintenance

Procedures for draining and refilling the cutterbar and gearboxes.

Knife and Disc Replacement

Instructions for inspecting, replacing knives, discs, and fixing elements.

Storage Procedures

Guidelines for cleaning, preserving, and storing the machine.

Trouble Shooting Guide

Common Operational Issues

Lists typical problems, their causes, and recommended solutions.

Headland Turn Position Issues

Addresses specific problems related to placing the machine in headland turn position.

Limited Warranty

Warranty Coverage and Conditions

Details the warranty period, coverage scope, exceptions, and terms.

Warranty Claim Procedure

Explains the process for submitting a warranty claim and required documentation.
