KUHN GMD802 - Swathing system; Right swath wheel

Disc mower
44
GMD802
Instructions for work
 Swathing system
The swathing system comprises:
- 2 Swath wheels.
The swath width is 2.40 m (7’10") approximately.
Right swath wheel
The swath wheel's lateral position (A) and angle (X) can
be adjusted.
Make sure that distance (J) equals at least
15 mm (0.6’’).
