Kurzweil SP6 User Manual

The Rear Panel
CC (VOLUME) Jack
10
GETTING STARTED GUIDE
CC (VOLUME) Jack
Use the CC (VOLUME) jack to connect a MIDI CC pedal (also known as a MIDI expression
or volume pedal). By default this pedal is assigned to control Program and Multi volume (pre-
FX).
For KB3 Organ Programs, the CC (VOLUME) pedal controls organ swell. Organ swell is
similar to Program volume, except volume can not be turned all the way down to silence. e
LCD display shows “KB3” when a KB3 Program is selected.
For User Multis, the CC pedal can be assigned to a dierent function for each Zone by using
Multi Edit Mode.
e optional Kurzweil CC-1 continuous control pedal will work best with the SP6, but it is
also possible to use third-party continuous control pedals designed for keyboards. Compatible
pedals should use a 10 kΩ linear-taper potentiometer, with a 1/4 inch tip-ring-sleeve (stereo)
plug with the wiper connected to the tip.
AUDIO OUT LEFT (MONO) and RIGHT Jacks
Use the AUDIO OUT jacks to connect to an amplier or mixer. See “Quick Start” on page
2 for details.
HEADPHONE Jack
Use the HEADPHONE jack located on the left rear panel of the instrument to listen to
the SP6 on stereo headphones. You will need a 1/4-inch-to-1/8-inch adapter in order to use
headphones that have a smaller mini plug connector.
When headphones are plugged in, audio is still transmitted from the AUDIO OUT jacks.

Kurzweil SP6 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black, Blue
User presets quantity	1024
Keyboard number of keys	88
Preset programs quantity	256
Maximum polyphony (notes)	128
Display type	LCD
DC input voltage	12 V
Power source type	DC
USB ports quantity	2
6.35 mm (1⁄4-inch) input	1

Weight and Dimensions

Depth	381 mm
Width	1333 mm
Height	146 mm
Weight	12360 g
