K-Series Components and their function
13
Active brake
To apply the brake, pull the brake lever forwards beside or
between your knees as far as possible.
To release the brake, push the brake lever backwards
beside or between your knees.
4.3 Backrest
Backrest cover
You can adjust the tension of the backrest cover as required.
Adjusting the backrest cover
Remove the backrest cushion.
Loosen the Velcro® tapes on the rear of the backrest cover
by simply pulling on them.
Tighten or loosen the tapes as required then reattach
them.
IMPORTANT
If the bands are set very loose, the tipping point of
your wheelchair is changed for the worse.
Backrest height
The height of the backrest can be adjusted. The adjustment
must be carried out by the specialist dealer.
