Kuschall K-SERIES User Manual

 K-Series Components and their function
19
 Perform the same setting on both sides.
IMPORTANT!
Do not overtighten the knurled screw as this can
damage its mechanism.
IMPORTANT!
Changing the wheel camber can impair or negate
the function of the parking brakes.
4.9 Rear wheel extension
Your wheelchair can be fitted with a rear wheel extension. The
rear wheel extension makes it possible to alter the position of
the rear wheel and thus the tipping stability of the
wheelchair. The adjustment must be carried out by the
specialist dealer.
4.10 Seat cushion
A suitable cushion is needed to provide an even pressure
distribution on the seat.
4.11 Seat position
The seat position and thus the tipping stability of your
wheelchair can be altered. The adjustment must be carried
out by the specialist dealer.
Seat height front (SHv)
The SHv can be adjusted. The adjustment must be carried out
by the specialist dealer.
Seat height rear (SHh)
The SHh can be adjusted by several centimeters. The
adjustment must be carried out by the specialist dealer.

Kuschall K-SERIES Specifications

General

Weight Capacity	130 kg
Foldable	Yes
Type	Active Wheelchair
Wheel Size	24 inches
Frame Material	Aluminum
Front Casters	5 inches
Seat Width	360 - 510 mm (14 - 20")
