K-Series Components and their function
21
Luggage carrier
Your wheelchair can be fitted with a luggage carrier. When
not in use, the luggage carrier can be folded up.
IMPORTANT
Only use the luggage carrier for the intended
purpose.
WARNING! Risk of tipping
Weight on the carrier changes the tipping behaviour
of the wheelchair.
- The wheelchair can tip forwards more easily when
the luggage carrier is loaded.
Transit wheels
WARNING!
When using transit wheels, the parking brakes no
longer have any effect and you cannot control your
wheelchair via the handrims.
If your wheelchair is too wide for certain applications, e.g.
trains/aeroplanes, narrow passageways, narrow doors, the
transit wheels can be used.
Switching to transit wheels
Lower the transit wheels into the operating position. To
do this, press the pin inwards until you can pull the tube
down.
Press the second pin in.
