K-Series Components and their function
15
Height adjustable, angled push handles
(optional)
The infinitely height adjustable push handles allow any
assistant to adjust the handles to a comfortable level.
To set the height of the push handles, loosen the bolt ,
push the handle to the desired position and tighten the
bolt again.
4.5 Sides
Side rest, infinitely height adjustable
Removing
Pull the side rest by the arm cushion out of the holder.
To adjust how easy or difficult it is to pull the side rest out
of the holder, change the degree to which the screws
are tightened.
Fitting
Push the side rest into the holder.
Adjusting the height
Loosen the screw of the retaining plate .
Move the armrest upwards or downwards until you reach
the desired height.
