Kutai electronics GCU-3000 User Manual

___________________________________________________________________________________________
16 GCU-3000
SECTION 6 : TERMINAL & WIRING DESCRIPTION
6.1 Connection Detail
PIN No.
DESCRIPTION
ATTENTION
1
AC Input (L1)
Connect to AC Input Phase R
3
AC Input (L2)
Connect to AC Input Phase S
5
AC Input (L3)
Connect to AC Input Phase T
7
AC Neutral Input (N)
Connect to AC Input Phase N
8
Battery Positive ( V )
Connect to battery positive (12/24V)
9
Battery Negative ( V )
Connect to battery negative
10
CT Secondary for (L3)
Connect to Secondary Phase T (L3) Monitoring CT
11
CT Secondary for (L2)
Connect to Secondary Phase S (L2) Monitoring CT
12
CT Secondary for (L1)
Connect to Secondary Phase R (L1) Monitoring CT
13
CT (COMM) Terminal Input
Connect to External CTs Common Position
14
Starter Motor Signal Output
Connect to Starter Motor.
Supply (+V) (Max. rated output 10 Amp)
15
Fuel Solenoid Signal Output
Connect to Fuel Solenoid or Fuel Valve Control.
Supply (+V) (Max. rated output 10 Amp)
16
Overload Alarm Signal Output
Used to Trip the AC Output Breaker.
Supply (+V) (Max. rated output 2.5 Amp)
17
Panel Illumination Output
Connect to the Panel Lamp
(Max. rated output 2.5 Amp)
18
Normal Operation Auxiliary Output
Connect to the Operation Indication Lamp
(Max. rated output 2.5 Amp)
19
Failure Signal Output
Used to Control External Alarm Buzzer.
Supply (+V) (Max. rated output 2.5 Amp)
20
Preheat Signal Output
Used to Control the Internal Heater.
Supply (+V) (Max. rated output 2.5 Amp)
21
Warm up Contactor Control Output
Connect to Warm up Contactor
(Max. rated output 2.5 Amp)
22
You defined signal Input 2
Negative Input When Action
23
You defined signal Input 1
Negative Input When Action
24
Low Fuel signal Input
Connect to Fuel Level Switch
25
High Water Temperature Signal Input
Connect to water temperature switch
26
Low Oil Pressure Signal Input
Connect to oil pressure switch
27
Remote Start Signal Input
Connect to A.T.S or remote start terminal
28
Remote Start Signal Input
Connect to A.T.S or remote start terminal
29
Magnetic Pick-up Input
Connect to Magnetic Pick-up to monitor speed
30
Magnetic Pick-up Input
Connect to Magnetic Pick-up to monitor speed
31
Idle Speed Control Signal Output (CO.)
Connect to Electronic Governor for idle speed
control
32
Idle Speed Control Signal Output (NC.)
Connect to Electronic Governor for idle speed
control
33
Idle Speed Control Signal Output (NO.)
Connect to Electronic Governor for idle speed
control
34
Block Heater Output
Connect to Block Heater
(Max. rated output 2.5 Amp)
35
Voltage Potentiometer Output
Connect to Automatic Voltage Regulator (GAVR)
36
Voltage Potentiometer Output
Connect to Automatic Voltage Regulator (GAVR)
