Kutai electronics GCU-3000 User Manual

___________________________________________________________________________________________
12 GCU-3000
3.16 CANBus J1939 Transducer KCU-04 (Optional)
The KCU-04 module is used with CPU equipped
engines using the J1939 CAN Bus protocol. It is
connected to any one of the four slots on the back of
the GCU-3000 controller.
For J1939 related settings refer to Setting Line (21).
Installing the KCU-04 provides the GCU with the
following information.
● Temperature reading in ˚C or ˚F
● Oil Pressure reading in Psi or Bar
● High temperature warning and shut-down alarm
● Low oil Pressure warning and shut-down alarm
● Over-speed warning and shut-down alarm
● Under-speed warning and shut-down alarm
● Low fuel level warning and shut-down alarm
When you connect the KCU-04 module the GCU
disables the High Temperature, Low Oil Pressure and
Low Fuel Level protections automatically and all related
programming lines are automatically eliminated. You
don’t need to install any of sensors, this information
now comes from the CAN Bus, and protections
relegated to the engine CPU. The GCU’s job is to show
warning, alarm and shutdown messages using the
universal icons on the front panel.
The GCU does not disable its own over speed and
under speed protection, Both of GCU and the engine
CPU will shut-down the generator for over speed.
3.17 System Setting Line-by-Line Programming Table
NO.
DESCRIPTION
SETTING
FACTORY
PRE-SET
1
Frequency (60 or 50 Hz)
00  60 Hz 01  50 Hz
00
2
How is the generator wired?
(3Ø 4W, 3Ø 3W, 1Ø 3W or 1Ø )
00  3Ø 4W 01  3Ø 3W
02  1Ø 3W 03  1Ø
00
3
Correct the Voltage reading on the display (If needed)
Add or subtract the amount on line 4 to your reading
00  Do not correct
01  Add volts from line 4
02  Deduct volts from line 4
00
4
Volts reading display correction (If needed)
01  99 V
05 V
5
(Faulty voltage) protection time delay
00  99 sec
(0  Do not Protect)
15
6
Set Under-Voltage protection
08  47 (80  470V)
18(180V)
7
Under voltage protection Warning or Shutdown
00  Warning
01  Shutdown
01
8
Set Over-Voltage protection
11  50 (110  500V)
25(250V)
9
Over-voltage protection Warning or Shutdown
00  Warning 01  Shutdown
01
10
Correct Amps reading on the display (If needed)
Add or subtract the amount on line 11 to your reading
00  Do not correct
01  Add amps from line 11
02  Deduct amps from line 11
00
11
Amps reading display correction (If needed)
01  99 A
05 A
12
Set the (CT)
Example : 5 if you use a 100/5 CT for current reading
(Choosing the wrong CT will give you a erroneous
current reading)
01  25/5 02  50/5 03  60/5
04  75/5 05  100/5 06  150/5
07  200/5 08  250/5 09  300/5
10  400/5 11  500/5 12  600/5
13  750/5 14  800/5 15  1000/5
16  1200/5 17  1500/5 18  1600/5
19  2000/5 20  3000/5
05
13
Over-load protection activation time delay
00  99 sec
(00  Option Cancelled)
00
