Kutai electronics GCU-3000 User Manual

___________________________________________________________________________________________
GCU-3000 13
NO.
DESCRIPTION
SETTING
FACTORY
PRE-SET
14
Setting the over-load protection
(One unit is equal 50 amps)
Example : 20 units is equal to 1000A overload
protection
20 * 50A = 1000A
01  60 (50  3000A)
02(100A)
15
Over-load protection Warning or Shutdown
00  Warning 01  Shutdown
00
16
Over-speed / Under-speed protection activation time
delay
00  99 sec
(0  Option Cancelled)
05
17
Magnetic Pick-up (MPU) used with the GCU-3000?
00  NO 01  Yes
00
18
RPM info taken from the generator or MPU
00  AC Hz 01  MPU
00
19
Over-speed protection setting
51  75 Hz
65 Hz
20
Under-speed protection setting
40  59 Hz
55 Hz
21
Use the Oil (PS-01) pressure sensor or get info from
J1939 (KCU-04) transducer
00  (None)
01  PS-01 Sensor
02  J-1939 + KCU-04
01
22
Oil pressure reading in Psi or Bar
00  Psi 01  Bar
00
23
If the (PS-01) Oil pressure sensor fails do I want a
Warning or a Shutdown
00  Warning 01  Shutdown
00
24
Low oil pressure protection activation time delay
02  99 sec
10
25
Use the (PS-01) sensor to detect low oil pressure
00  NO 01  Yes
00
26
Low oil pressure warning setting
Psi：00  99 45 Psi = 3 Bar
45 Psi
27
Low oil pressure Shutdown setting
Psi：00  99 14.5 Psi = 1 Bar
15 Psi
28
Backup oil pressure switch sender installed?
NO (Normal Open) or NC (Normal Close)
00  Installed but Not Used
01  NO 02 NC
02
29
Is the (TS-01) temperature sensor installed?
00  No 01  Yes
01
30
Temperature display
(You can change from C to F under operation)
00  Centigrade 01  Fahrenheit
00
31
If the temperature sensor (TS-01) fails do I want a
Warning or a Shutdown
00  Warning 01  Shutdown
00
32
High temperature protection activation time delay
02  99 sec
05
33
Use the temp sensor to detect high water temperature
00  NO 01  Yes
00
34
High temperature warning setting
(Every unit is equal to 5 Degree Centigrade)
10  20 units 18 = 194 F
18
(90 ˚C)
35
High temperature shutdown setting (HIGH / HIGH)
(Every unit is equal to 5 degree C)
10  24 units 21 = 221 F
21
(105 ˚C)
36
Is the (PS-01) temp sensor used to control the block
heater
00  NO 01  Yes
00
37
Block heater max temp OFF setting
00  50 ˚C
25 ˚C
38
Additional Temp switch type sensor installed
NO (Normal Open) or NC (Normal Close)
00  Not installed
01  NO 02  NC
01
39
Battery under voltage protection setting
08  23 Vdc
08 Vdc
40
Battery over voltage protection setting
13  35 Vdc
32 Vdc
41
Pre-heat timer setting
00  99 sec
06
42
Start attempt
01  09 Start Attempts
03
43
Cranking timer setting
2  30 sec
06
44
Magnetic Pick-up (MPU) used for verify engine start
00  No 01  Yes
00
45
Oil pressure sensor disengages starter (At 25 Psi)
00  No 01  Yes
00
