Kutai electronics GCU-3000 User Manual

___________________________________________________________________________________________
14 GCU-3000
NO.
DESCRIPTION
SETTING
FACTORY
PRE-SET
46
Additional oil pressure switch sensor to confirming
engine start
00  No 01  Yes
01
47
Set activation timer for the energize stop solenoid
(Time needed to pull the energize to stop Solenoid)
02  99 sec
10
48
Method used to stop the engine
(Energize to Stop or Energize to Start)
00  Energize to stop
01  Energize to start
00
49
Cool-down timer
00  60 min
00
50
Idle timer (Used only if governor capable)
00  60 min
00
51
Time in Warm up before connecting load contactors
00  99 sec
10
52
Activate the warning buzzer
00  NO 01  Yes
01
53
Fuel level indicator switch sender type
NO (Normal Open) or NC (Normal Close)
00  Not used
01  NO 02  NC
00
54
Low fuel level activation time delay
02  99 sec
10
55
Low fuel level Warning or Shutdown
00  Warning 01  Shutdown
00
56
Defined Alarm1 (switch type)
NO (Normal Open) or NC (Normal Close)
00  Do Not use Alarm1
01  NO 02  NC
00
57
Alarm1 activation time delay
02  99 sec
10
58
Alarm1 Warning or Shutdown
00  Warning 01  Shutdown
00
59
Defined Alarm2 (switch type)
NO (Normal Open) or NC (Normal Close)
00  Do Not use Alarm2
01  NO 02  NC
00
60
Alarm2 activation time delay
02  99 sec
10
61
Alarm2 Warning or Shutdown
00  Warning
01  Shutdown
00
62
Service and maintenance reminder
(Every unit is equal to 10 hrs) 20 x 10hr is a 200 hr
reminder
00  99
(00  No Service reminder)
00
63
Voltage and Amps display setting
00  Fixed Display
01  Cycle Display
01
64
Also display each phase to Neutral (L1-N, L2-N, L3-N)
In 4W 3Ø (Phase systems)
00  NO 01  Yes
01
65
Display only Hour Meter, Battery Volts, or Hertz at one
time or cycle though all readings
00  Hour meter
01  Battery voltage
02  Hertz
03  Display all values
02
66
To retrieve the last 15 Failure event from memory
program this line to Yes and press the Pen button
00  NO 01  Yes
00
67
Override shutdowns & start and stop the engine
manually
Useful when servicing the generator
00  Normal 01  Manual
00
68
Erase service log and maintenance warning signal and
reset service timer
00  NO 01  Yes
00
69
Enable R486 remote control by KCU-XX module
00  NO 01  Yes
00
70
KCU-02 module address setting
00  None
01  99
00
71
KCU-02 baud rate setting
01  115200 02  57600
03  38400 04  19200
05  14400 06  9600
07  4800 08  2400
09  1200
03
