4 Appendices
In this section you will find technical information about the Kvaser Leaf Light v2 and
its connectors.
4.1 Technical data
In Table 3 below you will find the Kvaser Leaf Light v2’s technical specifications.
CAN Channels 1
CAN Transceivers TJA1051T (Compliant with ISO 11898-2)
CAN Controller Built into the processor
CAN Bit Rate 40 kbit/s to 1 Mbit/s
Time stamp resolution 100 µs
Max message rate 8000 msg/s
Error Frame Detection Yes
Error Frame Generation No
Silent mode No
PC interface USB Hi-Speed
Power consumption Typical 90mA
Hardware configuration Done by software (Plug & Play).
Software requirements Windows XP or later. (For other operating systems, contact Kvaser
support.)
Dimensions 35 x 165 x 17 mm for body incl. strain relief
Weight 110 g
Operating temperature −20
◦
C to +70
◦
C
Storage temperature −40
◦
C to +85
◦
C
Relative humidity 0 % to 85 % (non-condensing.)
Table 3: Technical Specifications.
