Parts
6
Check parts and accessories
❶ Check all parts.
❷ Turning off source water before installation.
❸ Connect the body with the cold tap water.
(Connecting with hot water causes an out of order of the product.)
Before installation
pH testing drops
Stainless steel
diverter valve for
(under the counter)
cold water line
connection
Hose Stainless steel hose
Optional
In line filter
4.5cm
1.5cm
Drain line sink
(suction) attachment
Stainless steel faucet
head diverter valve
White pressure reducer
Screws for
wall mounting
C-block Power cord
Color
comparison table
User manual
Major Components
7
General body
❻
Power Cord Receptacle
❶ Housing : Houses all components.
❷ Stainless Steel Water Output Hose : Output for alkaline, acidic or purified water as selected by user.
❸ LCD Display : Displays pH, ORP, remaining filter life (both filters), error messages
and water flow rate.
❹ Touch sensors : Used to turn the Genesis on and off (standby mode), to select various levels of alkaline
and acid water and to select filtered only water: Also used to program the product.
❺ Water drain OUTLET (Quick Connect) : Connection for drain (tubing) from the product.
❻ Power Cord Receptacle : power cord plug connect
❼ Water supply INLET (Quick Connect) : Connection for water supply (tubing) to the product.
❽ Master ON/OFF power switch : To control power to the body
❽
Master ON/OFF power switch
❼
Water supply INLET (Quick Connect)
❸
LCD Display
❺
Water drain OUTLET (Quick Connect)
❹
Touch sensors
❷
Stainless Steel Water Output Hose
~Front View ₩~Rear View ₩
~Bottom View ₩
❶
Housing
