10. FINAL REDUCTION
10-1
AGILITY CITY 125
SERVICE INFORMATION
SPECIFICATIONS
Specified Oil: GEAR OIL SAE 90#
Oil Capacity: At disassembly : 0.2 liter
At change : 0.18 liter
SPECIAL TOOLS
Bearing puller, 10,12,15,18mm
TROUBLESHOOTING
Engine starts but motorcycle won‘t move
xDamaged transmission
xSeized or burnt transmission
xFaulty drive belt
xFaulty clutch
Abnormal noise
xWorn, seized or chipped gears
xWorn bearing
Oil leaks
xOil level too high
xWorn or damaged oil seal
SERVICE INFORMATION.......................10-1 FINAL REDUCTION INSPECTION......10-2
TROUBLESHOOTING..............................10-1 BEARING REPLACEMENT..................10-3
FINAL REDUCTION DISASSEMBLY....10-2 FINAL REDUCTION ASSEMBLY........10-4
Cortesia de / Courtesy of: www.batmotos.com
Recambios KYMCO en www.batmotos.com

KYMCO agility R16 125 Specifications

General

Displacement	124.6 cc
Transmission	CVT
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	100/80-16
Rear Tire	120/80-16
Fuel Tank Capacity	6.5 liters
Seat Height	780 mm
Bore x Stroke	52.4 mm x 57.8 mm
Compression Ratio	9.6:1
Wheelbase	1340 mm
Engine Type	4-Stroke
Starting System	Electric
Length x Width x Height	2050 mm x 735 mm x 1210 mm
Weight	120 kg (Dry)
