KYMCO BET & WIN 50 User Manual

1. GENERAL INFORMATION
1-14
BET & WIN 50
5mm bolt, nut
6mm bolt, nut
8mm bolt, nut
10mm bolt, nut
12mm bolt, nut
4.4_ 5.9
7.8_ 11.8
17.6_ 24.5
29.4_ 39.2
49.0_ 58.8
5mm screw
6mm screw, SH bolt
6mm flange bolt, nut
8mm flange bolt, nut
10mm flange bolt, nut
3.43_ 4.9
6.86_ 10.8
9.8_ 13.7
23.5_ 29.4
14.7_ 44.1
SPECIAL TOOLS
Tool Name
Tool No.
Remarks
Universal bearing puller
E030
Crankshaft bearing removal
Lock nut socket wrench
F001
Top cone race holding
Lock nut wrench,
F001
Stem lock nut tightening
Crankcase puller
E026
Crankcase disassembly
Bearing remover set, 12mm
(Spindle assy, 15mm)
(Remover weight)
E020
Drive shaft bearing removal/installation
Bearing remover set, 15mm
(Spindle assy, 15mm)
(Remover head, 15mm)
(Remover shaft, 15mm)
E018
Drive shaft bearing removal/installation
Bearing outer driver, 28x30mm
E014
Bearing installation
Clutch spring compressor
E027
Driven pulley disassembly/assembly
Crankcase assembly collar
E023
Driven shaft, crankshaft & crankcase
assembly
Crankcase assembly tool
E024
Crankshaft & crankcase assembly
Ball race remover
F005
Steering stem bearing races
Rear shock absorber compressor
F004
Rear shock absorber disassembly/assembly
Universal holder
E017
Flywheel holding
Flywheel puller
E001
Flywheel removal
Pilot, 12mm
E020
Drive shaft bearing installation
Bearing outer driver, 32x35mm
E014
Drive shaft bearing installation
Final shaft bearing installation
Bearing outer driver, 37x40mm
E014
Drive shaft bearing installation Final shaft
bearing installation Crankshaft bearing
installation
Outer driver, 24x26mm
E014
Driven pulley bearing installation
www.PlanDeGraissage.org

KYMCO BET & WIN 50 Specifications

General

Fuel System	Carburetor
Ignition	CDI
Starting System	Electric & Kick
Front Suspension	Telescopic Fork
Brakes Front	Disc
Brakes Rear	Drum
Tire Size Front	120/70-12
Tire Size Rear	130/70-12
Cooling System	Air Cooled
Transmission	Automatic
