2-2. Engine oil replacement
A. Place the machine on a level place.
B. Warm up the engine for several minutes
and stop it.
C. Place a container under the engine.
D. Remove the oil fill cap (1) and drain plug
(2) to drain the oil.
E. Reinstall the drain plug and tighten the
drain plug to specification.
F. Fill the engine with oil and install the oil fill
cap.
Be sure no foreign material enters the
crankcase.
CAUTION:
(1) Oil fill cap
(1)
(1) Oil fill cap
(2) Drain plug
Tightening torque:
Drain plug (engine):
30 Nm (3.0 m-kg, 22 ft-lb)
(2)
Recommended oil: see page 189.
Oil quantity: see page 189.
129
