Battery remove (MXU 300/250)
1. Make sure the ignition switch is OFF.
2. Remove the seat (page 46)
3. Remove the battery cover (1), by removing the
screws (2).
4. Release the rings and remove the rubber band
(3).
(2)
(1)
(1) Battery cover (2) Screws
(3) Rubber band
(3)
171
