5. Shift the battery (4) and the terminal leads
face yourself.
6. Disconnect the negative (-) terminal lead (5) from
the battery first, then disconnect the positive (+)
terminal lead (6).
7. Remove the battery.
(4) Battery (5) (-) terminal lead (6) (-) terminal lead
(6)
(5)
(4)
172
