FUSE REPLACEMENT (MXU 300/250)
The fuse box stored in the battery compartment
under the seat. The fuse box contains a spare
fuse.
The specified fuse is: 15 A
To replace a fuse:
1. Make sure the ignition switch is OFF.
2. Remove the seat (page 46)
3. Open the fuse box cap (3).
4. Pull the old fuse out of the fuse holder.
5. Push the new fuse in to the fuse holder.
6. Close the fuse box cap and install seat.
To prevent accidental short-circuiting, turn
off the main switch when checking or
replacing a fuse.
POTENTIAL HAZARD
Using an improper fuse.
WHAT CAN HAPPEN
An improper fuse can cause damage to the
electrical system which could lead to a fire.
HOW TO AVOID THE HAZARD
Always use a fuse of the specified rating.
Never use a material in place of the proper
fuse.
WARNING
CAUTION:
(1)
(2)
(1) Spare fuse (2) Fuse box (3) Fuse box cap
(3)
175
