Work Shop use only-- Replacing the ECU(2)
71
z Switch the Scooter off.
z Remove the seat unit.
z Removing the rear panelling.
z Remove the lighting cable.
z Remove ECU protect cover bolts and battery plug and front
connector.
z Disassemble the battery plugs (+)(-)and (1)(2) as picture--
z Disassemble the ECU’s plug as picture--
z Remove ECU bolts --.
z Disassemble the ECU--.
z Installation is in the reverse order of removal.
z Attached to wire diagram.
