Work Shop use only-- Removing and
installing the motor
72
z Switch the Scooter off.
z Remove the seat unit.
z Removing the rear panelling.
z Remove the lighting cable.
z Remove ECU protect cover bolts and battery plug and front
connector.
z Disassemble the battery plugs (1)(2) as picture--
z Disassemble the ECU’s plug as picture--
z Remove the rear wheels.
z Remove the motor stay bolts as picture.--
z Disassemble the electric motor.
To Next Page
