1. GENERAL INFORMATION
1-13
X-Town250/300 ABS
CABLE & HARNESS ROUTING
Tilt Switch
Fuel Pump Relay
Radiator Filler Cap
Coolant Reserve Tank
ECU
Winker Relay
Hi Beam Relay
Lo Beam Relay
Fi ECU
ABS ECU
(APPLY ABS MODE)
HYDRAULIC UNIT
Fan Relay
Starter Relay
ECU Relay
ABS ECU
(APPLY ABS MODE)
OiL Pressure Controller
Ignition Switch
