17. IGNITION SYSTEM
17-3
X-Town250/300 ABS
SPARK PLUG
For spark plug inspection and adjustment,
refer to page 3-5.
IGNITION COIL INSPECTION
Remove the seat and met-in box. (

2-6)
Remove the ignition coil.
IGNITION COIL CONTINUITY
TEST
Inspect the continuity of the ignition coil,
primary coil and secondary coil.
Measure the ignition coil resistances at 20℃.
Primary coil
3.57~4.83Ω
Secondary coil with
plug cap
10 ~ 14 KΩ
Secondary coil
without plug cap
6 ~10 KΩ
AC 110V
This is a general test. Accurate ignition
coil test must be performed with an
ignition unit tester.
＊
Ignition Coil
Primary Coil
Secondary Coil with plug cap
Secondary Coil without plug cap
