Kymeta u7 Series User Manual

© 2019 Kymeta Corporation and its affiliates. 7 08 March 2019
Kymeta™ u7 terminal usermanual
4 Package contents
4.1 u7 terminal packaging (configuration 1)
Box Contents
Box 1:u7 antenna (1) antenna
Box 2:ODUassembly (1) ODU mounting plate with attached RF chain - BUC, diplexer, LNB
(4) Screws
(4) Short stand-off posts
(8) Washers
(1) Loctite
(6) Cable ties
(1) O-ring
(1)
700-00009-001 Kymeta™ u7 terminal quick start guide
(1)
700-00011-000 Kymeta™ u7 terminal limited warranty
(1)
700-00008-001 Kymeta safety and handling guide
Box 3:I/O box (1) I/O box
(1) power cable
(8) screws and nuts
Box 4: ODUinterface cable (1) ODU interface cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
Box 5:Modem
(1) Modem
(1) Power cable
(8) Screws and nuts
(1) Ethernet cable
(2) N-type to F-type adapter
RF cables (accessory) (1) RX cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
(1) TX cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
