© 2019 Kymeta Corporation and its affiliates. 3 08 March 2019
Kymeta™ u7 terminal usermanual
2.1.3 Power
The power receptacle is a universal AC IEC 320-C14 on the back of the I/O box. Each I/O box ships with a US standard
Type B 3-pin plug.
2.1.4 Status light
The status light has three states:
Off, no light—no power
Yellow—failed to start
On, green—operational
If the status light is yellow, contact your Kymeta representative.
2.1.5 Recovery button
The Recovery button is a three-function pin-hole button. Use this button to reset the u7 antenna network and user
configuration if the u7 antenna local network is not responding.
Reset
To reset the u7 antenna network configuration to the factory default values:
1.
Make sure the u7 antenna is running.
2.
Press and hold the Recovery button for four seconds.
The LED on the u7 antenna will blink and then stay on indicating the network configuration was reset. The changes take
effect immediately; no restart is necessary.
Restore
To restore the u7 antenna network configuration and user configuration to the factory default values:
1.
Power off the u7 antenna.
2.
Press and hold the Recovery button, and then power on the u7 antenna.
3.
Release the Recovery button 30 seconds after the power is turned on.
Software image restore
To restore the u7 antenna software image to the factory default:
1.
Power off the u7 antenna.
2.
Press and hold the Recovery button, and then power on the u7 antenna.
3.
Release the Recovery button 60 seconds after the power is turned on.
✎ If the u7 antenna is reset or powered off within 3 minutes of the software image restore operation being
requested, the operation will not be completed and the original software image will remain.
Recover
If the u7 terminal is not responding, cycle the system power to reset.
