Kymeta u7 Series User Manual

© 2019 Kymeta Corporation and its affiliates. 8 08 March 2019
Kymeta™ u7 terminal usermanual
4.2 u7 terminal packaging (configuration 2)
Box Contents
Box 1: u7 terminal ODU (1) Pre-assembled ODU (ODU mounting plate (attached RF chain - BUC,
diplexer, LNB) installed on antenna)
(6) Cable ties
(1)
700-00009-001 Kymeta™ u7 terminal quick start guide
(1)
700-00008-001 Kymeta safety and handling guide
(1)
700-00011-000 Kymeta™ u7 terminal limited warranty
Box 2:ODUinterface cable (1) ODU interface cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
Box 3:I/O box
(1) I/O box
(1) Power cable
(8) Screws and nuts
Box 4:Modem (1) Modem
(1) Power cable
(8) Screws and nuts
(1) Ethernet cable
(2) N-type to F-type adapter
RF cables (accessory) (1) RX cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
(1) TX cable (three lengths available: 3.66 m, 7.62 m, 15.24 m)
