Kyocera ECOSYS M2535dn Servlce Manual

2PK/2PL/2PM/2PN
1-4-25
(8)Duplex solenoid
does not operate.
1. Broken duplex sole-
noid coil.
Check for continuity across the coil. If none, replace the
duplex solenoid.
2. Defective harness
between duplex sole-
noid and control
PWB (YC29), or
improper connector
insertion.
Reinsert the connector. Also check for continuity within the
connector harness. If none, remedy or replace the harness.
3. Defective control
PWB.
Replace the control PWB (See page 1-5-37).
(9)Cleaning lamp
does not turn on.
1. Defective harness
between cleaning
lamp (YC701) and
control PWB (YC28),
or improper connec-
tor insertion.
Reinsert the connector. Also check for continuity within the
connector harness. If none, remedy or replace the harness.
2. Defective cleaning
lamp (PWB).
Replace the cleaning lamp (PWB).
3. Defective control
PWB.
Replace the control PWB (See page 1-5-37).
(10)Paper indica-
tor is flashing when
paper is present in
the cassette.
1. Defective paper sen-
sor.
Replace the paper sensor.
2. Defective harness
between paper sen-
sor and control PWB
(YC18), or improper
connector insertion.
Reinsert the connector. Also check for continuity within the
connector harness. If none, remedy or replace the harness.
(11)A paper jam in
the paper feed/
conveying section
or fuser section is
indicated when the
main power switch
is turned on.
1. A piece of paper torn
from paper is caught
around registration
sensor or exit sen-
sor.
Check and remove if any.
2. Defective registration
sensor on the high
voltage PWB.
Replace the high voltage PWB (See page 1-5-43).
3. Defective exit sen-
sor.
Replace the exit sensor.
(12)Attention indi-
cator is lit when the
front cover is
closed.
1. Defective interlock
switch on the power
source PWB.
Check for continuity across the interlock switch. If there is
no continuity when the interlock switch is on, replace the
power source PWB (See page 1-5-40).
(13)When the trou-
ble occurs in the
DP.
-
Refer to the DP’s service manual.
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS M2535dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	1536 MB
Sound power level (standby)	27.5 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (printing)	51.3 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	65 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	439 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV, GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR
