Kyocera ECOSYS M2535dn Servlce Manual

2PK/2PL/2PM/2PN
2-1-11
2-1-4 Developing section
The latent image constituted on the drum is developed into a visible image. The developing roller contains a
3-pole (S-NS) magnet roller and an aluminum cylinder rotating around the magnet roller. Toner attracts to the
magnet sleeve since it is powdery ink made of black resin bound to iron particles. Developing blade, magne-
tized by magnet, is positioned approximately 0.3 mm above the magnet sleeve to constitute a smooth layer of
toner in accordance with the magnet sleeve revolution.
The developing roller is applied with the AC-weighted, positive DC power source. Toner on the magnet sleeve
is given a positive charge. The positively charged toner is then attracted to the areas of the drum which was
exposed to the laser light. (The gap between the drum and the magnet sleeve is approximately 0.32 mm.) The
non-exposed areas of the drum repel the positively charged toner as these areas maintain the positive
charge.
The developing roller is also AC-biased to ensure contrast in yielding by compensating the toner’s attraction
and repelling action during development.
Figure 2-1-15 Developing unit and toner container
1
3
4
6
7
8
5
2
1. Magnet sleeve
2. Magnet roller
3. Developing blade
4. Blade magnet
5. DLP screw A
6. DLP screw B
7. DLP case
8. Toner container

Kyocera ECOSYS M2535dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	1536 MB
Sound power level (standby)	27.5 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (printing)	51.3 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	65 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	439 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV, GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
