Kyocera ECOSYS M2535dn Servlce Manual

2PK/2PL/2PM/2PN
2-3-9
YC20 1 +24V4IL O 24 V DC 24 V DC power source
Connected to
the registra-
tion clutch,
paper feed
clutch and
developing
clutch
2 REGDRN O 0/24 V DC Registration clutch: On/Off
3 +24V4IL O 24 V DC 24 V DC power source
4 FEDDRN O 0/24 V DC Paper feed clutch: On/Off
5 +24V4IL O 24 V DC 24 V DC power source
6 DLPDRN O 0/24 V DC Developing clutch: On/Off
YC21 1 +24V4IL O 24 V DC 24 V DC power source
Connected to
the MP paper
feed solenoid
2 MPFDRN O 0/24 V DC MP paper feed solenoid: On/Off
YC23 1 +24V0 I 24 V DC 24 V DC power source
Connected to
the high volt-
age PWB
2 +3.3V1E O 3.3 V DC 3.3 V DC power source
3 ZCROSS I 0/3.3 V DC (pulse) Zero cross signal
4 FAN O 0/24 V DC Left cooling fan motor: On/Off
5 HEATN O 0/3.3 V DC Fuser heater: On/Off
6 SLEEP O 0/3.3 V DC Sleep mode signal: On/Off
7 MHVDR O 0/3.3 V DC Main charger output signal: On/Off
8 RTHVDR O 0/3.3 V DC Transfer (reverse) bias output signal: On/
Off
9 PSEL1 O 0/3.3 V DC Transfer (reverse) bias control signal: On/
Off
10 HVCLK O 0/3.3 V DC (pulse) Developing bias clock signal
11 REGN I 0/3.3 V DC Registration sensor: On/Off
12 TCNT O PWM Transfer current control signal
13 MCNT O PWM Main charger output control signal
14 THVDR O 0/3.3 V DC Transfer bias output signal: On/Off
15 CASE I Analog Cassette switch: On/Off
16 THERM I Analog Fuser thermistor detection voltage
17 +24V4ILR O 24 V DC 24 V DC power source
18 SGND - - Ground
19 SEPA - - -
YC24 1 +3.3V1E O 3.3 V DC 3.3 V DC power source
Connected to
the waste
toner sensor
2 TNFULL I 0/3.3 V DC Waste toner full detection signal
3 SGND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M2535dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	1536 MB
Sound power level (standby)	27.5 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (printing)	51.3 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	65 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	439 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV, GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
