Kyocera ECOSYS M2535dn Servlce Manual

2PK/2PL/2PM/2PN
1-3-48
U610 Setting system 1
Description
Makes settings for fax reception regarding the sizes of the fax paper and received images and
automatic printing of the protocol list.
Method
1. Press the start key.
2. Select the item to be set using the cursor up/down keys.
Setting the number of lines to be ignored when receiving a fax at 100% magnification
Sets the maximum number of lines to be ignored if the received data volume exceeds the record-
ing capacity when recording the data at 100% magnification. If the number of excess lines is
below the setting, those lines are ignored. If over the setting, they are recorded on the next page.
1. Change the setting using the cursor left/right keys or numeric keys.
* : Increase the setting if a blank second page is output, and decrease it if the received
image does not include the entire transmitted data.
2. Press the start key. The value is set.
Setting the number of lines to be ignored when receiving a fax in the auto reduction mode
Sets the maximum number of lines to be ignored if the received data volume exceeds the record-
ing capacity when the data is recorded in the auto reduction mode. If the number of excess lines
is below the setting, those lines are ignored. If over the setting, the entire data on a page is fur-
ther reduced so that it can be recorded on the same page.
1. Change the setting using the cursor left/right keys or numeric keys.
* : Increase the setting if a page received in the reduction mode is over-reduced and too
much trailing edge margin is left. Decrease it if the received image does not include all
transmitted data.
2. Press the start key. The value is set.
Item No. Description
Display Description
CUT LINE:100% Sets the number of lines to be ignored when receiving a fax at
100% magnification.
CUT LINE:AUTO Sets the number of lines to be ignored when receiving a fax in
the auto reduction mode.
CUT LINE:A4 Sets the number of lines to be ignored when receiving a fax
(A4R/LetterR) in the auto reduction mode.
Description Setting
range
Initial
setting
Change in
value per step
Number of lines to be ignored when
receiving at 100%
0 to 22 3 16 lines
Description Setting
range
Initial
setting
Change in
value per step
Number of lines to be ignored when
receiving in the auto reduction mode
0 to 22 0 16 lines

Kyocera ECOSYS M2535dn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6.9 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	14 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	1536 MB
Sound power level (standby)	27.5 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (printing)	51.3 dB
Sound pressure level (quiet mode)	49 dB
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	5 lines
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	65 W
Power consumption (PowerSave)	3.7 W
Power consumption (average operating)	439 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV, GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
